10mm Small Planetary Gear Motor 12V Low Noise Planetary DC Gear Motor For Smart Lock

10mm Small Planetary Gear Motor 12V Low Noise Planetary DC Gear Motor For Smart Lock

Brand Name:	Masing Motor
Model Number:	MS10PM10
MOQ:	1000
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100000piece/per month

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

RohS,CE,ISO

Product Name:

10mm Micro DC Planetary Gear Motor

Shaft Material:

Rohs Plastic

Efficiency:

Customized

Speed:

Customized

Gear Diameter:

φ10mm

Gearbox Type:

φ10mm Planetary Gearbox

Gears Material:

Plastic Gears

Micro Motor:

φ10mm Brushed Dc Motor

Key Words:

10mm Plastic Planetary Dc Gearbox Motor

Gearvox Materail:

Rohs Plastic Gearbox

Noise:

Low Noise

Torque:

0.01-1kgf.cm Or Customized

Packaging Details:

Carton Box

Supply Ability:

100000piece/per month

Highlight:

10mm Small Planetary Gear Motor

Small Planetary Gear Motor 12V

Low Noise Planetary DC Gear Motor

Product Description

10mm Small Planetary Gear Motor 12V Low Noise Planetary DC Gear Motor For Smart Lock

Product Overview

DC Planetary Gear Motor with 10mm diameter, offering low cost, small size plastic planetary micro gear motor solution for smart locks and beauty apparatus applications.

High Efficiency: 80%-55% efficiency operating at 1.2V-12V DC
Applications: Toys, door-locks, robots, SMART HOME, Electric Bicycle Locks, Cosmetic Instruments
Rated Speed: 10rpm-500rpm
Compact Size: φ10×13mm diameter, 10mm diameter, 13mm length mini motor
Gearbox Material: Plastic with φ10mm diameter
Suitable for small diameter, low noise and high torque applications
Motor Direction: CW & CCW available
Compatible with wheels - one shaft one wheel or one motor one wheel
Working Temperature: -40°C to +60°C
Low Noise & High Torque: 0.01-1kg.cm torque with low noise operation
Durable Design: Totally enclosed protection with permanent magnet construction for long lifespan
Samples available for testing

Technical Specifications

Speed (RPM)	30-80rpm
Continuous Current (A)	10-200mA
Efficiency	IE 1
Warranty	Others
Place of Origin	Guangdong, China
Brand Name	Masing Motor
Model Number	MS10PM10
Use	door-lock, robots, SMART HOME, Electric Bicycle Lock, Cosmetic Instrument
Type	4.5V Plastic DC Planetary Gear Motor
Torque	0.01-1kg.cm
Construction	Permanent Magnet
Commutation	Brush Motor
Protect Feature	Totally Enclosed
Product Name	M10 Brushed DC Gear Motor
Application	door-lock, smart home
Keywords	3V Plastic DC Planetary Gear Motor
Diameter	10mm
Material	Rohs
Noise	≤55DB
MOQ	1000Pcs
Voltage	1.2v-12v
Color	Customer's Request
Motor Type	DC planetary geared motor

Product Images

Motor Performance Data

10mm DC Plastic Planetary Gear Motor Typical Applications: door-lock, robots, SMART HOME, Electric Bicycle Lock, Cosmetic Instrument.

Voltage, rated torque, speed, current, power and shaft size can be customized as requirement.

Motor Model	Rated Voltage (V)	No Load Current (mA)	No Load Speed (r/min)	Load Current (mA)	Load Speed (r/min)	Load Torque (gfcm)	Output Power (W)	Stall Torque (gf.cm)	Stall Current (mA)
MS-10PM10	3.7	≤65	76	≤160	42	240	/	/	≤250

Output torque (gear motor): Output torque of motor (max efficiency point) * Reduction ratio * Gearbox efficiency

Output speed (gear motor): Output speed of motor / Reduction ratio

Number of Stages	Reduction Ratio	Gearbox Length "L"	Gearbox Efficiency
1	171K	7	70%

Packaging & Delivery

Packaging Details	Strong Carton 400pcs/box, or as you wish
Port	Shenzhen/Guangzhou/Shanghai
Selling Units	Single item
Single Package Size	37×27×24cm
Single Gross Weight	10.0kg
Supply Ability	100,000 Piece/Pieces per Month

Lead Time

Quantity (pieces)	1 - 100	101 - 1000	> 1000
Lead Time (days)	10	15	To be negotiated

Samples

Maximum Order Quantity	1 piece
Sample Price	$15/piece

Certifications & Factory

Product Classification

Applications

Driverless, Artificial intelligence, Intelligent transportation, Health care, Smart city, Automotive supplies, Security monitoring, 5G communication, Smart home, door-lock, robots, Electric Bicycle Lock, Cosmetic Instrument.

Frequently Asked Questions

Q1: Are you factory?

A1: Yes, we are factory. Main products include micro geared motor, brushless DC motor, DC motor and DC planetary gear box etc.

Q2: What is the quality of the planetary reducer?

A2: Our gear motors have been sold to Japan, Germany, the United States, the United Kingdom, Indonesia, Singapore and other countries. Most customers provide feedback that they operate well, have low noise and large torque, which is exactly the product they are looking for.

Q3: How can you guarantee the quality?

A3: We have 100% finished product inspection before delivery and no defective products returned.

Q4: How long is the delivery?

A4: Delivery time depends on the quantity you order. Usually it takes 15-25 working days.

Q5: Can we test samples?

A5: Yes, we have R&D and Testing Center. Customized samples and freight are charged.

Q6: How to confirm the payment?

A6: We accept payment by T/T, PayPal, and other payment methods. Please contact us before using other payment methods. 30-50% deposit is available, with balance paid before shipping.

Q7: About customized gearbox?

A7: As a gearbox manufacturer with R&D capability, we support customers to provide gearbox shape, required reduction ratio and output speed. We will develop customized products for you. Or you can provide your own R&D products, and we will optimize the structure, production and assembly for you.
