N20 Gear Motor 1000 RPM with Customizable Shaft and Low Noise for Robotics and Toys

N20 Gear Motor 1000 RPM with Customizable Shaft and Low Noise for Robotics and Toys

Brand Name:	Masing Motor
Model Number:	MS-GM12N20
MOQ:	1000
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100000piece/per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS ,CE, ISO,16949

Product Name:

N20 Gear Motor 1000 Rpm

Gearbox Shaft:

φ3mm ,φ4mm ,M3,M4,M5 Or Customized

OEM & ODM:

Accepted

Gearbox Diameter:

φ12mm

Brush Type:

Metal Brush/Carbon Brush

Gearbox Type:

Spur Gearbox

Rated Voltage:

DC1.2V-12V

Direction Of Motor:

CW&CCW

Usage:

Laser,Locks,Toys,3D Printer,Robots

Motor Type:

N20 Gear Dc Motor

Packaging Details:

Carton box

Supply Ability:

100000piece/per month

Highlight:

1000 RPM N20 Gear Motor

Customizable Shaft DC Gear Motor

Low Noise Micro Metal Gear Motor

Product Description

N20 Mini Micro Metal Gear Motor

DC 6V 12V 30RPM-1000RPM N20 micro metal gear motor with GA12-N20 configuration, ideal for robotic arms, robots, and precision applications.

Technical Specifications

Rated Voltage	DC 1.2V - 12V
Rated Speed	5 RPM - 3000 RPM
Motor Size	φ12mm * 15mm
Gearbox Size	φ12mm * 10mm
Rated Torque	0.01 kgf.cm - 2 kgf.cm
Shaft Diameter	φ3mm, φ4mm or customized
Reduction Ratio	1:10 to 1:1000 (customizable)
Weight	10g
Noise Level	≤55 dB
Certifications	CE, RoHS, EU, ISO, 16949

Key Features

Professional quality control with comprehensive testing
Meets EU environmental standards with low energy consumption
Available in CW & CCW rotation directions
Customizable voltage, speed, torque, and shaft configurations
Multiple shaft types available: Round, D-cut, Screw, Trapezoidal
Metal, steel, or copper gears compliant with RoHS standards
Free sample testing available

Product Images

Typical Applications

Packaging & Delivery

Packaging: Strong carton (1000pcs/box) or customized packaging
Shipping Ports: Shenzhen, Guangzhou, Shanghai
Unit Weight: 10.0kg per package
Supply Capacity: 100,000 pieces per month

Lead Time

Quantity (pieces)	1 - 100	101 - 1000	> 1000
Lead Time (days)	10	15	To be negotiated

Samples & Certifications

Sample Price: $10/piece (maximum order quantity: 1 piece)
Certifications: CE, RoHS, EU, ISO, 16949

Industry Applications

Frequently Asked Questions

What's the price?

As a professional manufacturer, our pricing is based on client specifications including speed, voltage, and other requirements. Contact us for a customized quote.

What's the MOQ?

We offer flexible minimum order quantities depending on product complexity and production schedule. Contact our sales team to discuss your specific requirements.

What's the delivery time?

Standard delivery is within one month during slack seasons. For large quantities during busy seasons, additional time may be required. We offer expedited production for urgent orders.

Can you send samples before ordering?

Yes, we provide samples for quality confirmation. Shipping available via UPS, TNT, FedEx, or DHL.
