Dc Gear Motor Dc Motor 25mm Diameter Spur Gearbox Motor For Small Electric Cat Toilet Motor

Dc Gear Motor Dc Motor 25mm Diameter Spur Gearbox Motor For Small Electric Cat Toilet Motor

Brand Name:	Masing Motor
Model Number:	MSGM25A370
MOQ:	1000
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100000piece/per month

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

ROHS CE ISO

Product Name:

370 Geared Motor

Dimension:

32mm

Protect Feature:

Totally Enclosed

Certification:

RoHS,CE

Direction Of Rotation:

CW/CCW

Gearbox Material:

Plastic

Gears:

Plastic Gears

Shaft Material:

Carbon Steel Or Stainless Steel

Torque:

0.1-1kg.cm

Motor Type:

12 Volt Gear Reduction Motor

Packaging Details:

Carton box

Supply Ability:

100000piece/per month

Highlight:

25mm dc gear motor

25mm dc reduction gear motor

32mm dc gear motor

Product Description

DC Gear Motor 25mm Diameter Spur Gearbox Motor for Small Electric Cat Toilet Motor

Product Overview

High-performance DC gear motor with 25mm diameter metal spur gearbox, designed for small electric applications including cat toilet motors. Features customizable voltage, speed, and power specifications.

Voltage: DC 1.5V-24V
Speed: 2RPM-1000RPM (Customizable)
Power: 0.1W-10W (Customizable)
Gearbox Diameter: Ø25mm (Metal construction)
Reduction Ratio: 1:10-1:1000 (Customizable)
Compatible Motors: RF-300, RF-310, RF-370, RS-385, RS-365, RS-390
Output Bearing: Ball bearing / Sleeve bearing
Shaft Options: Ø3mm, Ø4mm, Ø5mm (Bare / D-Cut / Double D-Cut / Pin Hole / Keyway)
Shaft Material: Carbon Steel or Stainless Steel
EU Environmental Standards: Low energy consumption, low noise

Technical Specifications

Speed (RPM)	1.5RPM-1500RPM
Continuous Current	10mA-500mA
Efficiency	70%
Warranty	3 Months - 1 Year
Place of Origin	Guangdong, China
Brand Name	Masing Motor
Model Number	MSGM25A370
Gearbox Material	RoHS 25mm gearbox
Gear Ratio	1:15-1:1000
Construction	Permanent Magnet
Rotation Direction	CW or CCW
Protection Feature	Totally Enclosed
Noise Level	≤55DB
MOQ	1000 Pcs
Lifetime	100-1000 hours
Certifications	CE, RoHS, ISO

Product Images

Technical Diagram

Packaging & Delivery

Packaging: Strong Carton (1000pcs/box) or customized packaging

Port: Shenzhen/Guangzhou/Shanghai

Package Size: 12×10×24mm

Gross Weight: 0.08kg

Supply Ability: 100,000 Pieces per Month

Lead Time

Quantity (pieces)	1 - 100	101 - 1000	> 1000
Lead Time (days)	10	15	To be negotiated

Samples: Maximum order quantity: 1 piece | Sample price: $5/piece

Certifications

Factory & Products

Applications

Suitable for various industries including driverless systems, artificial intelligence, intelligent transportation, healthcare, smart cities, automotive supplies, security monitoring, 5G communication, smart home, and more.

Medical Equipment	Sphygmomanometer, Massaging mattress, Air pump, Urine Analyzer
Business Machines	Intelligent robot, Copiers and Scanners, 3D Printers, Tattoo pen
Electric Powered Equipment	Electric toothbrush, Electric tool, Adult products, Electric toy car, Electric curtain
Smart Home	Intelligent window opener, Vacuum cleaner, Smart coffee machine, Hair dryer, Fascia gun, Fan, Air cleaner, Hair removal device, Door lock
Food and Beverage	Hand Blenders, Blenders, Mixers, Coffee Machines, Food Processors, Juicers, Fryers, Ice Makers, Soy Bean Milk Makers
Robotics	Servicing robotics, Food delivery robot, Reception robot, Medical serving robot, AGV & AMR, Conveying robot, Inspection robot

Frequently Asked Questions

Q1. What are your main products?

A1: We currently produce Brushed DC Motors, Brushed DC Gear Motors, Planetary DC Gear Motors, Brushless DC Motors, Stepper motors etc. You can check the specifications on our website or email us for recommendations based on your requirements.

Q2. How do you ensure motor quality?

A2: We have comprehensive inspection procedures including incoming materials inspection, production process tour inspection, and final inspection to ensure qualified products before shipping.

Q3. What's the minimum order quantity?

A3: Our minimum order quantity depends on different motor models. Please email us for specific requirements. We typically do not accept personal use motor orders.

Q4. Can you send me your price list?

A4: Due to hundreds of different products and varying specifications, we don't offer a standard price list. However, we provide quotes within 24 hours upon receiving your inquiry.

Q5. Do you offer customization services?

A5: Yes, we can customize voltage, speed, torque, shaft size/shape, and add accessories like wires, connectors, capacitors, or EMC components as per your requirements.

Q6. What's your lead time?

A6: Generally, standard products require 25-30 days, while customized products may take longer. Lead times are flexible and depend on specific order requirements.

Important Note: Please refer to the rated voltage used by our motor. Voltage exceeding the specified range may cause the machine to burn.
