370 Miniature DC 6v12v24v Turbo Worm Gear Reducer Motor With M5 Threaded Shaft For Range Hood And Barbecue Machine

Name: 370 Miniature DC 6v12v24v Turbo Worm Gear Reducer Motor With M5 Threaded Shaft For Range Hood And Barbecue Machine
Brand: Masing Motor (Shenzhen) Co., Ltd
SKU: MS-GM3246Z370
Availability: InStock

Brand Name:	Masing Motor
Model Number:	MS-GM3246Z370
MOQ:	1000
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100000piece/per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

RohS,CE,ISO,16949

Product Name:

370 Micro Worm Gear Motor

Gearbox Shaft:

Round,D-cut ,M6,M5

Motor Type:

RF-370

Rated Voltage:

DC3V-24V

Brush Type:

Metal Brush /Carton Brush

Direction Of Motor:

CW & CCW

Protect Feature:

Drip-proof

Gearbox Diameter:

32mm*46mm

Rated Torque:

0.5kgf.cm~30kgf.cm

Efficiency:

IE 3

Packaging Details:

Carton Box

Supply Ability:

100000piece/per month

Product Description

Title:

370 Miniature DC 6v12v24v Turbo Worm Gear Reducer Motor With M5 Threaded Shaft For Range Hood And Barbecue Machine

Description:

Rated Voltage:DC3.0v-24v
Rated Spped :2rpm-500rpm
Please refer to the rated voltage used by our motor,the voltage exceeding the range of use of our voltagemay cause the machine to burn.
Motor default direction:CW&CCW
Working temperature:-40~+60°c
Motor Type:Brushless motor or Brushed motor
Motor Model:RF-370
Motor size :Diameter 24.4mm ,Lenght :30.8mm
Motor Power:1W-100W High Power
Gearbox diameter :φ32mm
Gearbox type :Planetary gear box
Gears Material:Plastic ,Copper ,steel,Powder metallurgy or customized
Suitable for Various Applications: As mentioned by the user, this motor is suitable for various industries, including medical devices, smart home, electric bicycles, boats, cars, fans, and home appliances, making it an excellent choice for multiple use cases.
We can provide samples for your test.
Every product must pass quality inspection before shipment

Key attributes:

Rated Speed(RPM)

3rpm-500rpm

Continuous Current(A)

20mA-500mA

Efficiency

IE3

Warranty

3Months-1Year

Place of Origin

Guangdong, China

Brand Name

Masing Motor

Model Number

MS-GM3246Z370

Use

Auto shutter, binding machine, automatic TV rack , money counter,spot light, tissue machine , office equipments, household appliances,automatic actuator

Type

Micro Worm Gear Motor

Rated Torque

0.1kgf.cm-30kgf.cm

Construction

Permanent Magnet

Commutation

Brush /Brushless

Direction of motor

CW &CCW

Product Name

12v geared motor

Rated Voltage

DC3V-24V

Keywords

370 DC 6V Worm Gear Motor

Gearbox size

32mm*46mm

Weight

0.2KG

Noise

≤55DB

MOQ

1000Pcs

Life TIme

Customized

Gearbox Shaft

Customer's Request,M5,M6, D-cut or Round or Double D-cut

Motor type

rf-370 dc motor

Product Photo:

Product Spec:

N20 DC Worm Gear Motor Typical Applications:

Smart Locks: Door Lock, Fingerprint Lock, Express Cabinet Lock, Bike Lock ,Smart Home

Financial Medical Equipment: 3Doodler ,Projector ,Robots,Public equipment

Voltage,ratedtorque,speed,curent,powerand shaftsize can be customized as requrement.

370 Miniature DC 6v12v24v Turbo Worm Gear Reducer Motor With M5 Threaded Shaft For Range Hood And Barbecue Machine 3

Packaging and delivery:

Packaging Details

Strong Carton 400pcs/box, or as you wish.

Port

Shenzhen/Guangzhou/Shanghai

Selling Units:

Single item

Single package size:

37X27X24cm

Single gross weight:

10.6kg

Supply Ability:

Supply Ability

100000 Piece/Pieces per Month

Lead time:

Quantity (pieces)	1 - 100	101 - 1000	> 1000
Lead time (days)	10	20	To be negotiated

Samples:

Maximum order quantity: 1piece

Sample price:

$10/piece

Certifications:

Advantages :

1.Company Advantage:

A. Our company is a large-scale professional manufacturer deeply trusted by domestic and overseas customers, integrating development, production, wholesales and service.

B. To ensure high-quality and best service ,kingly built up professional teams engaged in research,product engineering and sales.

C. We have 5years experience in the design of the research and development, With strong technology developing ability and manufacturing capability, advanced equipment

2. Product Advantage:

A. Variety of products,quality guaranteed, products are widely used

B. Advanced product testing equipment

C. Product flexibility, customize according to the requirements of the clients any special develop all kinds of molds, Independent research and development since the open mold products

D. Products through a variety of certification(CE,RoHs,ISO,Reach)

E. Some products have patent certificate

Factory Show:

Product Classification:

Applications:

Small home appliances.models, power tools, communication equipment, medical devices,

health care equipment, toys and fitness equipment and other products.

Our producs have a wide range of applications, more application scenarios are waiting for you to unlock.

Driverless,Artificial intelligence,Intelligent transportation,Health care,Smart city,Automotive supplies,

Security monitoring,5G communication,Smart home

Medical equipment	sphygmomanometer, Massaging mattress, Air pump, Urine Analyzer.
Business Machines	intelligent robot,Copiers and Scanners, 3D Printers, Tattoo pen.
Electric powered equipment	Electric toothbrush,Electric tool,adult erotica products,Electric toy car,Electric curtain.
Smart Home	Intelligent window opener ,vacuum cleaner, Smart coffee machine,hair drier,Fascia gun,fan,air cleaner,Hair removal device,door lock,Intelligent door lock.
Food and Beverage	Hand Blenders, Blenders, Mixers, Coffee Machines, Food Processors, Juicers, Fryers, Ice Makers, Soy Bean Milk Makers.
Robotics	Servicing robotics, Food delivery robot, Reception robot, Medical serving robot, AGV & AMR, Convenying robot, Inspection robot.
